Maximum Servo Torque | 111oz/in @ 4.8V, 139oz/in @ 6.0V, 167oz/in @ 7.4V |
Programmable | Yes |
Servo Size Category | Standard |
Input Voltage | 4.8V ~ 6.0V ~ 7.4V |
Product Height | 1.48" (38 mm) |
Servo Type | Digital |
Connector Type | Universal |
Maximum Servo Speed | 48 rpm @ 4.8V, 58rpm @ 6.0V, 72rpm @ 7.4V |
Product Length | 1.59" (40 mm) |
Rotation Range | Continuous |
Product Width | 0.77" (20 mm) |
Application | Robotic |
Product Weight | 1.90 oz (53g) |
Spline Count | 24 - Tooth |
Water-Resistant | No |
Bearing | Dual Ball Bearing |
Bushing Or Bearing | Bearing |
Gear Type | Metal |
Wire Gauge | 25 AWG |
Servo Operating Voltage | 4.8 - 7.4V (HV) |
